Fire alarm systems are categorised into three main types under British Standard BS 5839: Category M (Manual), Category L (Life Protection), and Category P (Property Protection). Understanding these distinctions is important for building owners to ensure they meet fire safety regulations, satisfy insurance conditions, and protect occupants and property effectively using appropriate fire detection equipment.
Fire alarm systems fall into three main categories - Manual (M), Life Protection (L), and Property Protection (P). Choosing the right fire alarm system category and grade, incorporating suitable detector types like smoke detectors or heat alarms, is essential for compliance and effective active fire protection .
When selecting a fire detection and alarm system , understanding categories (purpose/coverage) and grades (technical complexity/reliability) is key. This includes choosing the right detector types, whether it's an optical smoke alarm, heat detector, or even a combined smoke and carbon monoxide alarm.
Grade A systems are the highest quality, featuring control panels, various detector types (could include optical smoke, ionisation, or heat alarms), and sounders, backed by a secondary power supply. They meet BS EN 54 standards. Lower grades (D-F) are common residentially, like a mains smoke alarm (Grade D) connected to the electricity supply with battery backup, or simpler battery-powered smoke alarms (Grade F), potentially using a 9V or long-life lithium battery. Maintaining your smoke alarms, including testing the battery to check functionality, is vital. Failure is a leading factor in fire-related deaths. Non-compliance can lead to fines.
Category M systems rely on human activation via break-glass call points. They lack automatic fire detection (no smoke detector or heat detector units are automatically activated). Suitable only where occupants are alert.
Per BS 5839, call points must be on all escape routes (max 45m travel). This ensures access to trigger the alarm system. Standard sounders then provide the alert.
Best suited for:
Not suitable for sleeping accommodations or high fire risk areas where rapid detection is needed.
Category L systems use automatic detection systems designed to protect life. They incorporate detectors (like optical smoke or heat alarms) that identify fires without human intervention. There are five subcategories:
L1 offers the most complete fire protection. L2 is common for offices. L3 suits shopping centres/care homes. L4 provides basic escape route warning. These systems ensure that when one senses smoke or heat, the alarm sounds to facilitate safe evacuation. In larger L category systems, interlinked smoke alarms (wired or potentially wireless interlinked smoke alarms) ensure all alarms in the property sound simultaneously when one is triggered.
Category P systems primarily aim to minimise property damage via early fire detection. Often required by insurers.
Two subcategories:
These systems focus on detecting fire early to allow intervention, potentially involving connection to the fire service or a monitoring centre.
Selecting appropriate detection equipment is important. Different detector types designed to detect various fire signatures exist:
Modern systems often use multi-sensor detectors. Some advanced domestic alarms, like certain FireAngel models, incorporate sophisticated sensor technology.
Beyond categories, types of fire alarm system architectures vary:
Conventional are simple. Addressable offer pinpointing. Intelligent systems are smart, reducing unnecessary alarm alerts. Getting advice from a qualified electrician or fire safety professional is recommended when choosing or installing systems, especially mains smoke alarm types. When you buy fire alarms, ensure they are fully certified (e.g., to BS EN 54 for components, or BS 5839 for the system). Consider needs like systems for people hard of hearing – these may use a flashing strobe light and vibrating pad linked to the main alarm system. These strobe lights come on when the alarm is triggered and are useful for people with hearing difficulties.
Leading manufacturers include Honeywell, Siemens, Mircom, Silent Knight, Fire-Lite, and Potter Electric. Domestic brands like FireAngel and Kidde are also prominent for smoke alarm and carbon monoxide alarm solutions, often offering alarms with 10-year sealed batteries. (Kidde is a well-known brand; searching for a "replacement for Fireangel" or specific "heat alarm bundle" deals indicates user interest in these brands).
Innovations focus on reducing false alarms, improving remote monitoring, and smart building integration. Devices designed for people with specific needs (e.g., the hard of hearing) are also improving, like linked alarms with flashing strobe lights. The aim is always faster, more reliable detection and alert functions. Local fire and rescue services often offer advice or home safety visits. Always fit smoke alarms according to guidance.
